We spent a whole episode on what the engine tells you. Tokens per second, time to first token, batching efficiency. All of that is the view from inside the software.
And today we flip the board over and look at the metal underneath it.
Daniel's question picks up exactly there. He says we did inference benchmarking from the engine's perspective, and now he wants the other side of the equation. Hardware level monitoring, on a Linux box, running open weight models. And his framing is the part that stuck with me. When people talk about hardware for local AI, the conversation is one resource. How much VRAM does the model need. Will it fit. How much is left over.
Like the model is a suitcase and the GPU is the overhead bin.
That's the whole conversation. And Daniel's point is that capacity is one number out of a whole board of them. So he's asking what else is worth watching. Compute utilization, memory bandwidth, memory controller activity, clocks, power, temperature, throttling. Then the rest of the box. CPU, system RAM, disk, PCIe, CPU to GPU traffic. And then the distinction I think is the real question underneath all of it. Consumption versus saturation. A GPU with nearly all its VRAM allocated is not the same thing as a GPU that is saturated, and a model that fits comfortably in memory can still be badly limited. So, what do you actually measure, what does it mean, and what would you check first on a slow server.
And the tooling question follows from that. NVIDIA versus AMD, which utilities for quick troubleshooting, which for continuous monitoring and alerting.
Right. So the through line here is that one GPU utilization number is not a measurement. It's an average of several different physical mechanisms wearing the same name, and the work is pulling them apart.
Here's the scene I want in everyone's head. A Linux box, one GPU with a lot of VRAM, an open weight model loaded. Something like DeepSeek. And the community conversation about whether this machine can run it stops at does it fit.
Fit is a yes or no question. It's not a performance question.
Correct, and that's the first thing to unlearn. VRAM capacity is a feasibility check. It tells you whether the model loads. It predicts almost nothing about how fast it will run. Fitting is the beginning of the question, not the end of it.
So if I've got a hundred gigabytes of model sitting in a hundred and forty gigabytes of VRAM, what have I actually established?
That you can start. That's it. You have established that the weights are resident and you won't be paging them in from system memory on every token. Which matters, but it's a floor, not a ceiling.
It's the difference between a car that has fuel in it and a car that's fast.
Well, and even that undersells it. Because the thing that actually determines your tokens per second is usually not the capacity at all. It's the bandwidth of the memory the weights live in. You can have a model that fits in a card with enormous headroom and still be badly bandwidth limited, because the model is small enough to fit and the card's memory is slow.
So a card with more memory can be slower than a card with less memory.
Constantly. That's the whole trap. Capacity is the spec on the box that people can compare easily. Bandwidth is the spec that actually governs decode.
Which gives us the two ideas for today. One, the counter isn't broken, it's over aggregated. GPU utilization collapses a bunch of mechanisms into one number. And two, consumption is not saturation. A resource can be almost fully allocated and still not be the thing that's holding you back.
And so the arc is this. What the GPU counters actually measure, then why decode is structurally memory bound, then the rest of the system, then consumption versus saturation properly, then the tooling, NVIDIA versus AMD, and finally how you'd actually walk up to a slow server and figure out what's wrong.
Let's start where the numbers come from. What is the GPU even telling you when you ask it how it's doing?
So the canonical answer on the NVIDIA side is DCGM, the Data Center GPU Manager, and specifically its profiling module. Module eight, if you're reading the docs. It exposes a big family of low overhead hardware counter metrics.
And what's in the family?
Graphics Engine Activity is 1001. SM Activity is 1002. SM Occupancy is 1003. Tensor Activity is 1004. Memory bandwidth utilization, which is really DRAM activity, is 1005. Then the pipe activities, FP64, FP32, FP16, at 1006, 1007, 1008. PCIe transmit and receive bytes at 1009 and 1010. NVLink transmit and receive bytes at 1011 and 1012. Default sample rate is one hertz, and you can push it down to a hundred milliseconds minimum.
A hundred milliseconds is fast enough to catch a stall between decode steps.
It is, and that turns out to matter later. But here's the caveat that I think is the single most important sentence in the documentation, and it's NVIDIA's own. SM Activity counts warps that are waiting on memory requests as active.
Say that again.
A warp that is stalled on a memory read is counted as active. The docs say it plainly. Active does not necessarily mean a warp is actively computing.
So the number that people screenshot and post as proof their GPU is working hard is partly counting warps that are doing nothing but waiting.
And NVIDIA even gives you a threshold, which is refreshingly blunt. A value of zero point eight or greater is necessary but not sufficient for effective use of the GPU. Below zero point five likely indicates ineffective usage.
Necessary but not sufficient. That's a very careful sentence from a company that would love to sell you more GPUs.
There are also two practical gotchas. Profiling counters require admin privileges, and that goes back to Linux driver 418.43. And some metrics cannot be collected at the same time. There's multiplexing inside the counter hardware, so if you crank the sample rate up and ask for everything, you can get zeros back.
And then people see zero percent and panic.
They open an issue. The card is fine. You asked it for incompatible things too fast.
So now the mechanism behind the thing Daniel specifically asked about. High memory usage, low computation. Why.
Because decode is structurally memory bound, and it's not a tuning problem, it's arithmetic. Take the H100. It has 989 teraflops of BF16 compute and 3.35 terabytes per second of HBM bandwidth.
Those two numbers are wildly different in scale.
They are, and the roofline model tells you how they interact. You divide compute by bandwidth and you get a ridge point. For the H100 that's roughly 295 floating point operations per byte.
Meaning what, in plain terms?
Meaning if your workload does at least 295 operations for every byte it pulls from memory, you're compute bound and the card's math units are your limit. If it does fewer, you're memory bound and the card's memory bandwidth is your limit. And decode steps during generation have arithmetic intensity of about one to five flops per byte.
One to five, against a ridge at two hundred ninety five.
Sixty to two hundred times to the left of the ridge. Not close. There is no amount of tuning that moves a workload two orders of magnitude across a roofline. Decode lives on the memory bound side, permanently.
So the card is pulling weights out of HBM as fast as it can and doing almost nothing with each byte.
And there's a field note that makes this concrete. A production H100 decode deployment, observed at four percent compute utilization.
Four.
Four. DRAM read activity running flat, meaning the memory subsystem was working hard the whole time. And over fifty percent of the cycles in the attention kernel stalled waiting on HBM.
So the answer to Daniel's question is that the GPU isn't lying. It's busy. It's busy waiting.
The line from that writeup is the one I'd put on a wall. Decode is a streaming memory workload wearing a deep learning costume. And then, the number that matters for decode is not teraflops, it is terabytes per second.
That reframes the entire purchasing conversation.
It does, and there's a second mechanism that I think is even more satisfying once it clicks, because it explains why the utilization counter reads high while nothing useful happens. It's about how the tensor cores actually execute.
Go on.
On Hopper, the bfloat16 GMMA path. The tensor core does not multiply an arbitrary sized matrix. It executes fixed sized fragments. The fragments are sixty four rows tall.
Sixty four rows, fixed, regardless of what you asked it to do.
Regardless. So picture a decode step with eight concurrent requests. Each request contributes one new token, so one row of real data. Eight real rows.
And the fragment is sixty four rows.
So you have eight real rows and fifty six rows of padding, and the tensor core executes all sixty four because that's the shape it's built to execute.
The GPU is multiplying zeros.
At high speed, drawing full power, reporting high tensor activity, and delivering the throughput of eight tokens.
That's the aha. That's the whole thing. The counter is telling the truth about the wrong noun.
And it gets worse with the padding, because padding rows still consume memory bandwidth. So you're not just wasting compute cycles, you're wasting the resource you were actually short on.
So the fix, if there is one, is decomposition. Stop looking for a better single number and start asking what specifically the GPU is waiting on.
And the good news is the counters for that exist. They're just not the number on the front of the dashboard.
Alright, so the GPU is busy multiplying zeros. Which raises the obvious next question. What is it waiting on, and is the answer even on the GPU?
Very often it isn't. And this is where the framing shifts. Inference is not one GPU operation. It's a pipeline, and the GPU is one stage of it. The GPU can be perfectly available while the rest of the system fails to feed it work fast enough.
So the better first question is what is the GPU waiting for.
Which is exactly the framing one of the writeups used. Stop asking whether the GPU is busy and start asking what it's waiting on. So let's walk the non GPU resources. CPU preprocessing and tokenization first.
Because before a token exists, somebody has to turn text into integers.
Somebody has to tokenize, build the batch, prepare the inputs. And the measurement here is striking. CPU time reaching up to thirty percent of decode execution at batch size five hundred twelve, on a model that is not large, OPT one point three billion.
Thirty percent of decode time is the CPU.
And the same work found a noticeable GPU idle gap between decoding steps, attributed to CPU processing time. So the GPU finishes a step, and then sits there while the CPU assembles the next one.
And that gap grows with batch size.
It grows with batch size, because there's more input to prepare. So the exact configuration where you'd expect the GPU to be most efficient is the configuration where the CPU eats the most of your time.
Which is a beautiful inversion of the usual story. People scale batch size up to use the GPU better, and hand more work to the part they weren't watching.
The same paper measured cache behavior too. L1 hit rates of twelve percent or less. L2 hit rates of two percent or less. And both get worse as batch size climbs.
Two percent on L2. Basically nothing is staying in cache.
Which means almost every access goes out to memory. And memory bandwidth is the thing we already established is the bottleneck. So it compounds.
Now give me the consumption versus saturation distinction properly, because that's the heart of this.
This is where it gets good. At maximum batch size in that same work, average DRAM read utilization was between forty eight and seventy seven percent.
So the memory was working, but not flat out.
Not flat out. And meanwhile average compute, warps actually in flight, never exceeded thirty five percent. And the metric called Unallocated Warps in Active SMs sat between forty and sixty six percent.
Unallocated warps. Meaning there were warps ready to run and the scheduler had nowhere to put them.
The paper's phrasing is that something is preventing warps from being scheduled. DRAM bandwidth saturation as the primary bottleneck, with most GPU compute capability sitting idle.
So you have a resource that is saturated and a resource that is merely consumed, in the same machine, at the same moment.
And that's the distinction Daniel asked for, in one measurement. Memory bandwidth saturated. Compute consumed but not saturated. Two different diagnoses with two completely different fixes.
And here's the pairing that resolves it, I think.
Model FLOPs Utilization and Memory Bandwidth Utilization. MFU and MBU. MFU tells you what fraction of the card's math throughput you're actually using. MBU tells you what fraction of its memory bandwidth you're using.
And the diagnosis falls out of the two of them together.
When MBU approaches one hundred percent while MFU stays low, you have confirmed that memory bandwidth is your ceiling and your system is operating correctly.
It's the sentence that turns low utilization from a problem into a diagnosis. Your card is fine. Your model is memory bound. That is what running a large language model on a GPU normally looks like.
So all the dashboards with the red ninety percent threshold baked in are alarming on healthy systems.
Constantly. Which is why the autoscaling story gets so ugly. Picture a system that scales out on a utilization trigger. Utilization is high, so it spins up another replica.
Adding replicas means splitting the traffic, so each replica gets a smaller batch.
Smaller batch, less fragment fill on those sixty four row GMMA fragments, more padding. Which keeps utilization high. Which triggers more scaling.
They're paying for more GPUs to sustain the misleading signal.
A feedback loop that spends money to keep the number that alarms you alive.
There's also the other direction. Bigger GPUs making utilization look worse.
Yes. Upgrade the accelerator, keep the pipeline the same, and you get a faster GPU waiting on the same old CPU. Utilization drops, because now the card is even less busy while it waits.
You spent the money and the number got worse, and the number was right.
Right. Which is why clock speeds, power, temperature and throttling belong in this conversation. Those are saturation signals that never show up in the utilization percentage at all.
Explain.
A thermally throttled GPU can report perfectly healthy utilization while running at a reduced clock. Utilization is a ratio. If the denominator shrinks because the card is running slow, the ratio can look great while absolute throughput is awful.
So the one number everyone watches is structurally blind to the failure that hurts most in a hot rack.
And AMD gets this shape right, incidentally. RDC exposes power throttle time and thermal throttle time as explicit health fields. That's the correct shape for this. Not a utilization percentage, a duration spent throttled.
What about offload and multi GPU?
When weights or the KV cache spill into system memory, PCIe and system RAM bandwidth stop being footnotes and become first class constraints. Suddenly your host memory bandwidth matters as much as the card's.
And you'd never know it from the card.
From the card, everything looks ordinary. With multiple GPUs, interconnect traffic becomes its own observable. That's why DCGM exposes NVLink transmit and receive bytes at 1011 and 1012. It's not decoration. On a multi GPU deployment the interconnect can be your ceiling.
Okay. So we know what to look for. Now, what do you actually type?
Split it by job. If you're troubleshooting interactively, right now, on one machine, the answer is nvidia-smi and its neighbors. nvidia-smi takes query options. You can ask for the whole report, you can ask for specific device categories, memory, utilization, power, clock. It loops with the right flag. It outputs CSV or XML, which is how it ends up in scripts. And it's backed by NVML, so there are Python bindings if you'd rather write the query.
What about the eye candy.
nvtop is the htop shaped one, and I'll come back to it, because it punches far above its weight. nvitop is the NVIDIA process viewer. btop and htop for the CPU side, iostat for disk.
That's the interactive tier.
That's the interactive tier. Then there's the tier for questions like what happened at three in the morning on Tuesday. That's DCGM plus dcgm-exporter into Prometheus into Grafana. dcgm-exporter feeds the time series, so you get history, and you get alerting.
DCGM's own health side?
Health watches, diagnostics with four run levels, and policies that alert on ECC and thermal events. DCGM 4.6.1 came out in August, under Apache 2.0, which matters for anyone who needed to care about licensing. And dcgmi dmon streams fields to your terminal if you want the live version without building a stack.
Then there's the third tier, which is different in kind.
Profiling. Nsight Systems for timelines, Nsight Compute for per kernel counters. That's where you go when you need to know which kernel is the problem, not which resource. And there's a conflict worth knowing about. DCGM profiling counters and Nsight can't run at the same time. You have to pause the one to run the other.
You have to stop your monitoring to profile.
There's a command for it, pause and resume, but yes. You cannot have both live on the same card simultaneously.
Here is where the story stops being symmetric, because the two vendors do not ship the same shape of telemetry.
They don't. And the interesting part is that it isn't really about which company has better tools. It's about architecture. Start with what AMD ships. amd-smi, which replaced rocm-smi. MIT licensed, with C plus plus, Python and Go libraries, JSON and CSV output.
Which sounds competitive on paper.
On the single machine level it is. Then RDC, the ROCm Data Center tool, which is a daemon, rdcd, plus a CLI, rdci. And RocProfiler for the profiling tier.
AMD has published the mapping between their fields and DCGM's.
They have, which is helpful. In July they put out a blog mapping RDC onto DCGM equivalents. Power and thermal throttle time against DCGM's two violation fields. XGMI read and write against NVLink. ECC via RAS. And their busy percentage fields against SM Activity, SM Occupancy and Tensor Activity.
On the single machine, the correspondence is there.
On the single machine it's there. Here's the asymmetry. AMD SMI has no daemon and no metrics endpoint.
No daemon at all?
No daemon, no endpoint. It reads and controls one machine. Fleet collection is left to whatever you build on top of its libraries. Whereas NVIDIA ships dcgm-exporter and the Kubernetes GPU Operator. So the fleet story is a product for one vendor and a project for the other.
That's not a small distinction for anyone running this at scale.
It isn't. A comparison scored DCGM seventy six out of a hundred against AMD SMI at seventy, and the widest gap was exactly there, in fleet integration.
The single machine gap is fourteen points of nuance and the fleet gap is the difference between configuring something and building something.
That's a fair way to put it.
What about the honest cross vendor answer. Is there a tool that just works on both?
nvtop is the standout, and I want to give it credit properly. Version three point three two supports AMD, Apple, Huawei Ascend, Intel, NVIDIA, Qualcomm Adreno, Broadcom VideoCore, Rockchip, MetaX, Enflame, Tenstorrent, Iluvatar CoreX. That's a remarkable list. And it plots GPU and memory utilization, temperature, power, clocks, and PCIe receive and transmit load.
PCIe load is a nice touch, given everything we just said about offload.
It's exactly the metric the offload conversation needs, and it's right there in the free tool. But here's the limit, and I want to be straight about it. No vendor neutral tool provides consistent hardware counter or profiling telemetry across NVIDIA and AMD.
Why not? It seems like a solved problem on its face.
Because the signals don't always measure the same physical quantity. There's an open project that explicitly refuses to alias AMD signals onto NVML shaped names for exactly this reason. Their argument is that AMD's graphics activity counter and NVIDIA's SM utilization counter sample at different scopes. They're not the same measurement with two names. They're two different measurements that happen to sound similar.
A vendor neutral dashboard would be presenting two different quantities under one label.
Which is worse than no dashboard, because it looks comparable. nvtop gives you a consistent interactive view, and that's real value. The deep counters stay vendor specific, and there's no abstraction over that as of today.
What's the practical takeaway for someone running a mixed fleet?
Use nvtop as your eyes for the quick look, everywhere. Then accept that the deep telemetry is two stacks, and staff for that. It's not going away because someone writes a wrapper.
So back to the slow server. Where would you actually start?
You're all describing my setup like it's a problem.
I've been doing this for years and I don't use any of that. I know when a card's unhappy.
By looking at it.
By listening to it. A memory bandwidth bound workload has a sound. It's the fan ramping and holding, steady, no oscillation. Compute bound is choppier. I called one in front of a room of people once and they asked me to leave.
You were asked to leave a room for identifying a bottleneck.
They were deploying at the time. It made them nervous.
How do you monitor, then. Because you clearly monitor.
I've got a gauge in the case. I built the case, so I mounted it myself. It's a mechanical gauge, the kind that goes on a pressure cooker. I read it by tapping it.
A pressure gauge.
The needle moves when the card's working. If it jumps when I tap the case, the workload's stalling. If it holds, it's streaming. I've kept a notebook of the readings for years. The software said everything was fine on a Wednesday and the gauge had been low for two days. Card died Thursday.
The gauge called it.
I've never trusted a dashboard since, and I don't intend to start.
The whole practice of watching counters.
It's a substitute for knowing the machine. You've got people watching nine numbers who've never once had the case open. Buying a dashboard instead of learning your hardware.
There is something to that. The counter tells you about a class of hardware. The ear tells you about yours.
I've had one of these cards and I don't have it now. Sold it when I moved. Point stands.
Alright. Herman, the order. Somebody walks up to a server that's slow.
Check throttling and clocks first. It's cheap, it's one command, and it rules out an entire class of problems before you touch anything interesting. A throttled card will make every downstream measurement look strange.
Then.
Then the pairing. Memory bandwidth utilization against compute utilization. That single comparison tells you which ceiling you're pressed against. High MBU with low MFU is a healthy memory bound system. Both high is a compute bound workload. Both low means you haven't found the real bottleneck yet and you should stop looking at the GPU.
If both are low.
CPU time and the inter step idle gap. That's where the pipeline shows up. If the GPU is waiting between steps, the answer isn't on the GPU.
Then PCIe and offload traffic, if weights or KV cache have spilled.
Disk last, and only if you're actually swapping. Disk is the one people check first and it's almost never the answer.
The framing to leave people with. You're not hunting for a bad number. You're looking for which resource is saturated and which is merely consumed.
Different diagnoses, different fixes. And only one of those two fixes is buying a bigger GPU.
The one thing I'd flag as an open question. As models get bigger and partial offload becomes routine rather than an edge case, does the GPU centric monitoring model survive? The interesting telemetry may be migrating off the card entirely, onto the interconnect and the host.
Nobody's shipping a clean cross vendor answer for that layer yet.
